Frequency source module
Review of the product In electronic circuits, the frequency source – This is a device that provides a reference frequency, heterodin frequency and clock signal. There are many circuitry implementations, such as quartz generators, dielectric generators, transistor generators, sources, etc.
Description
marker
Review of the product
In electronic circuits, a frequency source is a device that provides a reference frequency, heterodin frequency, and clock signal. There are many circuitry implementations, such as quartz generators, dielectric generators, transistor generators, frequency sources based on phase autofrequency adjustment, and atomic clocks used in satellite systems.
Frequency accuracy, frequency stability, amplitude stability and phase noise are invariably the most important indicators of a frequency source. A frequency source made in the form of a product of certain dimensions and shapes is called a frequency source module. A device that converts one frequency into several output frequencies is called a multi-output frequency source.
Scope of application
A frequency source is required in all circuits requiring reference frequency, heterodin frequency and clock signal.
Typical technical parameters
| Name of the parameter | Output frequency range | Frequency accuracy | Frequency stability | Phase noise | Power output | Operating temperature | Constructive implementation |
| Model indicators | 1 MHz ~ 100 GHz, optionally | about 5~10 ppb, to order | about ±1×10−5, to order | about 80~120 dBn/Hz @ 10 kHz, to order | 10 dBm to order. | -40 °C ~ +85 °C, to order | Modular construction, customized |
As part of the module - a frequency source with FAHR and a generator
Key features of the design of the main components
This unit, being a key node of technical control, requires high frequency purity, high stability, good temperature stability and low phase noise. Design should take into account circuitry, design and technology and necessarily use an integrated approach.
The company at all stages of the project actively interacts with the customer on engineering aspects, helps to improve the system of indicators and fill gaps in the technical agreement; at the stage of engineering implementation, full technical support is provided, it is possible to go to the facility to manage the installation and commissioning until the successful completion of the project.
